Light source: 1000 Watt white LED.
CRI:Ra≥90
Expected lifetime: 20,000 hours.
Colour temperature: 6500 Kelvin.
38000 lummens (max beam angle).
Zoom range:6°~45°Linear high speed zoom,the spot is uniform and consistent in any range.
Focus: high precision glass lens, electron linear focus.
Prism: 1 four-prism.
Frost: 1-independent frost effect.
Rotating gobo wheel: 1 interchangeable gobo rotator, 6 optional pattern pieces.
Fixed gobo wheel: 1 fixed gobos +7 pattern pieces +open, CW/CCW rotation, variable speed.
Gobo outside diameter: 27mm.
Max. Image diameter: 22mm.
Max Thickness: 3.5mm.
Gobo material: high-temperature coated glass.
Color wheel: 6 dichroic colors and clear, “Rainbow effect” in both directions.
CMY: infinite color mixing.
CTO: 6500K-2700K.
Pan/Tilt movement: 540˚/270˚,adopting a function which resets 32bit accurately and automatically Strobe: 1-20Hz.
Dimmer: 0-100%, mechanical linear dimming.
Control channels (DMX): 36/33/52
Protocol: DMX-512 RDM
Display: OLED
Power input, nominal: AC 100-240V 50/60Hz.
Max. Power consumption: 1107W.
Max current: 11.15A PF: 0.99.
Main fuse: 250V / 15A.
Power input: self-contained power cord.
DMX data input/output: Chassis 3-pin.
Weight: 36.5kg.
IP rating: IP20.
Material: Aluminum, copper, steel, plastic, iron.
Mounting points: 4 fixed folding lamp hook + attachment points for safety wire.
Operating range: 14˚F to 113˚F (-10˚C to 45˚C)
Startup range: -13˚F to 113˚F (-25˚C to 45˚C)
Storage range: -39.9˚F to 140˚F ( -40˚C to 60˚C)
Cooling: Active fan
Humidity: ≤85%
EMC: EN 55103-1:2009, EN 55103-2:2009, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013,
GB/T 17743-2007, GB 17625.1-2012
Safety: EN 60598-2-17:1989/A2:1991, GB 7000.1-2015, GB 7000.217-2008
