I MIX 4 L005644
Scroll on photo to zoom in or Click to enlarge
I MIX 4 L005644
Compact, portable mixing console, 2mono + 2 stereo input, 1bus, USB interface
Price
Please login to see the price.
  • Features

    4-way mini mixing console.
    2/4mic/line input, 48V phantom power, be used for condenser microphone.
    2 way stereo line input.
    q; 3.5mm CD input(I MIX 1 A NO).
    2 band EQ, +/- 15d8 EQ at 80 Hz & 12KHz.
    Main output control (L/R).
    Headphone output control.
    RCA input/output.
    1 way Subsidiary output(I MIX 1 NO).
    4 band LED level indicator.
    Compact structure, which can be used in different locations.
    Convenient for operating.
    External supply power (100-265V 50/60Hz), which can be used in any country.
    USB recording / playing function.

  • Technical Specifications

    Frequency response: 20 Hz to 20 kHz.
    THD: <0,008 %.
    Residual noise: Main output - 103 dB, subsidiary output: -90 dB.
    Gain scope: Mic input -20 dB to + 45 dB, Line input -20 dB to +25 dB.
    Phantom power: +48 V DC.
    EQ: Hi ± 15 dB @ 12 kHz, Low ± 15 dB @ 80 Hz.
    Max output: Main output + 21 dBu, headphones + 18 dBu.
    Input impedance: Mic 2,3 k bal, Line 20 k bal, CD/RCA input 24 k unbalanced.
    Output impedance: Main 120, RCA 1k, Headphone 25.
    Level indicators: (Clip), 0, -10, -20.
    Supply power: AC 100/240 Volt, 50/60 Hz, DC 12V power supply.
    Consumption: 11 Watt.
    Dimensions: 220 x 210 x 68 mm.
    Net weight: 0,98 Kg.
