Low-cost, comprehensive, all-in-one amplifier for commercial and industrial applications.
Features:
4x microphone or line inputs with Euroblock terminals.
2x Aux input, with RCA jacks, and a media player module.
1x remote microphone input, with RJ45 terminal.
Phantom power and VOX control for all microphone channels.
Acceptable wide range input level.
Recordable user voice alarm.
Three-layer priority muting, with EMC (External Evacuation Message control) input.
Built-in user-selectable pre-announce chime and siren for evacuation.
Zone selection and chime control with contact closure.
Advanced protection system includes current limiting, over-current, and thermal protection.
Desktop & 19" rack mountable type.
Input sensitivity for full output at maximum gain
Balanced Microphone Channels: -36 dB +/- 3 dB.
Balanced Line Channels: -6 dB +/- 3 dB.
Balanced remote microphone station: 0 dB +/- 3 dB.
Balanced EMC: 0 dB +/- 3 dB.
Unbalanced Link-Out / Rec-Out: 0 dB +/- 3 dB.
Unbalanced Aux-In: -6 dB +/- 3 dB.
Frequency response
at 1 Watt from speaker out tap, 100 Hz - 10 kHz: +1,5 / - 3 dB.
Tone Control
100 Hz, 15 kHz: +/- 12 dB, +/- 3 dB.
Signal-to-noise ratio, at rated power output: Less than 90 dB.
Crosstalk: -70 dB at 1 kHz.
Rated Output Power @ THD 0,5%: 480 Watt.
Total Harmonic Distortion (THD) at 1 kHz rated power: Less than 0,5 %.
Phantom power: +48 Volt DC.
Power Band Width at 1 kHz from speaker out tap: 80Hz - 15kHz with less than 0,5 % THD.
DC Output Offsete: Less than +/- 3 mV.
Operating temperature / Humidity at non-condensing: 0°C - 40°C at 95% Humidity.
Dimensions: 420 x 88 x 320 mm
Net weight: 11,2 Kg.
Dimensions: 53 x 43 x 21 Cm.
Weight: 12 Kgs.
