FOS WDmx TRX L005096
Scroll on photo to zoom in or Click to enlarge
FOS WDmx TRX L005096
Wireless DMX Transmitter/Receiver device Power 6W , transmitting range 300 meters , Interface rate: 250000bp / s ,Channel spacing: 5MHz.
Price
Please login to see the price.
  • Technical Details

    The WIRELESS DMX system is compact, lightweight and stylish. Utilizing AFHSS - Adaptive Frequency Hopping Spread Spectrum technology from Wireless Solution Sweden AB, the wireless system transmits or receives safe and reliable DMX data without any delay and interference. Ideal for rental, mobile show, event, club, DJ, etc.
    Features
        Adaptive Frequency hopping technology - AFHSS
        Completely interference free
        Worldwide 2.45G ISM unLicense Frequency
        Transmit 512 channels (1 universe) of DMX data
        Maximum 16 universes of DMX in one area
        One-button-go for quick setup
        Plug and play, no need configuration for IP address
        Point-to-point, point-to-multipoint, multipoint-to-multipoint operation
        Housing available in red, blue, black color
        Compatible with all W-DMX .
    Specifications
        Transmission distance: 500m (line-of-sign)
        Latency: <5mS
        Antenna type: 5dBi
        XLR in: 3pin & 5pin male
        IP rating: IP20
        Power supply: AC 120V or 230V 50-60Hz
        Dimension: 145mm x 100mm x 57mm
        Weight: 1.40kg

Manual
