The FOS HYDOR BSW PRO (L007882) is a powerhouse of a fixture, designed to be a "do-it-all" workhorse for outdoor festivals, large-scale events, and architectural installations.
Its primary strength lies in its IP65 rating combined with a high-output 500W LED engine, making it versatile enough to replace separate Beam, Spot, and Wash fixtures in your rig.
1. Optical Performance & Light Engine
The heart of the unit is a high-density LED engine designed for long-throw applications.
Light Source: 500 Watt White LED module.
Color Temperature: 7000K (Daylight cool).
Luminous Flux: Estimated ~25,000–30,000 lumens (varying by zoom angle).
Beam/Spot/Wash Modes:
Beam: 3° for sharp, narrow aerial effects.
Spot: Mid-range zoom for crisp gobo projection.
Wash: Up to 45° with the integrated frost filter for wide stage coverage.
Front Lens: Large-diameter antireflective lens for a uniform beam field.
2. Physical & Environmental Construction
Designed specifically for the rigors of touring and outdoor use:
Housing: Magnesium alloy. This is why it weighs only 28kg.
Protection Rating: IP65 (Dust-tight and protected against water jets from any angle).
Cooling System: Intelligent temperature-controlled fan system with a "Silent Mode" for theater applications.
Pan/Tilt: 540° Pan and 270° Tilt with 16-bit resolution and automatic repositioning if the head is knocked out of place.
3. Comprehensive Effect Suite
Color System: Linear CMY: Infinite color mixing.
Linear CTO: Color temperature correction (7000K down to 3200K).
Fixed Wheel: 12 dichroic colors + open.
Gobos:
Rotating Wheel: 7 interchangeable glass gobos (bi-directional rotation, indexing, and shake).
Static Wheel: 12 fixed metal gobos for beam shaping and break-ups.
Prisms: 4-facet Circular. Linear Prism.
Note: These can often be overlaid to create complex, multi-layered patterns.
Animation Wheel: A dedicated dynamic disk for fire, water, or cloud effects.
4. Control & Electronics
Protocol: DMX-512, RDM (Remote Device Management), and Wireless DMX (built-in receiver).
DMX Channels: Typically operates in 3 modes (Standard, Basic, Extended), likely ranging from 24 to 34 channels.
Connectivity: IP65-rated 3-pin In/Out. Powercon TRUE1 In/Out.
500W white LED module
7000K colour temperature, CRI 69.5
Illuminance: 6013 lx @ 20 meters (minimum beam angle), 161 lx @ 20 meters (wash mode).
Zoom range: 3° to 45°.
Motorised zoom and focus.
Frost filter.
12 dichroic colour filters, with rainbow and half colour position.
CMY and CTO colour mixing.
12 static gobos + open.
7 rotating gobos + open (Glass gobos only: outer diameter 23 mm, image size 18 mm, thickness 1.1 mm).
Gobo shake function for both wheels.
Animation wheel.
4facet linear and circular combinable prisms.
Linear, 16bit dimming and strobe effects.
Power input 100/240 Volt AC, 50/60 Hz.
Working temperature: -10 to +40 °C
DMX512 controllable with 29 channels.
RDM compatible.
Wired or wireless connection.
IP65 protection, suitable for indoor or temporary outdoor events.
16bit Pan & Tilt movement, 540 / 270 degrees.
3pin XLR, and truepowercon input and output connections.
Touch display.
Fixture size: 357 x 274 x 713 mm.
Net weight: 28.7 Kg.
Dimensions: 46 x 53 x 86 Cm.
Weight: 34 Kgs.
