FOS Artisan IP66

Product code:L007912

3D multisource IP66 Wash/Beam moving head featuring a primary source of 19 x 50-watt RGB + Lime (2800K) 4-in-1 LEDs. It includes a backlit 3D pixel source with 210P LEDs at 0.2W RGB 3-in-1, offering a high color rendering index , color temperature range of 2400-10000K, virtual color wheel, providing rich saturated , pastel color hues,motorized zoom range of 6-55 degrees ,supports ArtNet, sACN, DMX-RDM protocols, selectable dimmer curves, robust magnesium alloy housing, true PowerCon in/out,17kg

Why choose FOS

2 years warranty

Description

Technical Specifications
FOS Artisan IP66 - Product Code: L007912
Primary Light Source: 19 x 50W RGB + Lime (2800K) 4-in-1 LEDs
Secondary Pixel Source: 210 x 0.2W RGB 3-in-1 LEDs (Backlit 3D effect)
Zoom Range: Motorized Linear Zoom 6° – 55°
Color Temperature: Linear adjustment from 2400K to 10000K
Housing Material: Robust Magnesium Alloy
IP Rating: IP66 (Dust-tight & protected against powerful water jets)
Weight: 17 kg

Optical & Color Performance
High CRI: The addition of the Lime chip fills the spectral gap of standard RGB, providing superior white light and natural skin tones.
Virtual Color Wheel: Pre-programmed presets for quick access to saturated and pastel hues.
3D Pixel Mapping: The 210-LED background allows for complex "eye-candy" effects and textures behind the main lenses.
Control & Connectivity
Protocols: Supports ArtNet, sACN, and DMX-RDM for seamless network integration.
Dimming: selectable dimmer curves (Linear, Square, I-Square, S-Curve) for smooth theatrical fades.
Power: Industry-standard True PowerCon In/Out for secure, weather-sealed daisy-chaining.
Data: Standard DMX XLR and RJ45 Ethernet ports.

Why These Specs Matter

The 6° Beam: At its narrowest, the 50W chips will produce a very dense, punchy beam that can cut through high-output stage environments.

Magnesium vs. Aluminum: At 17kg, this unit is easier to rig on outdoor towers and temporary scaffolding than older aluminum-housed IP65 heads, which often exceed 25kg.

Lime Element: This is critical for outdoor architectural "white-washing" or high-end broadcast where standard RGB often looks "flat" or "digital."

Light Source / Optics

Main light sources：19x 50W RGBW(2800K) 4in1
Backlight LED：210x 0.2W RGB 3in1 LED
Expected lifespan：40,000 H
Motorised zoom with 6° to 55°.

Effects

RGBW colour mixing
Pixel control on the main light sources.
Hive aurora type effects, with RGB colour mixing, and matrix application control capabilities.
Macros or full control of the pixel main LED sections.
Linear colour temperature change.
Virtual colour wheel.
Smooth linear dimmer and strobe effects up to 20 Hz.

Technical Specifications

Input voltage: 100/240 Volt AC, 50/60Hz.
Maximum power consumption: 950 Watt.
Pan 540°, Tilt 270°, 16bit, auto repositioning.
IP66 magnesium alloy housing.
IP65 connectors for RJ45, power and DMX.
Compatible with ArtNet and sACN protocols.
Supports RDM.
DMX control with 26, 31, 50 and 127 Channels.
Environmental temperatures for operation: +45°C, -18°C.
Fixture Dimensions: 349 x 216.5 x 350 mm
Net weight: 17 Kg.
