Description

Introducing our cutting-edge multi-head lighting design, featuring an impressive array of capabilities. This unit is equipped with five powerful 120W RGBL 4-in-1 LEDs, allowing for precise pixel control. Additionally, the outer circle is adorned with 120 0.5W RGB 3-in-1 LEDs, which can be controlled in three separate sections for enhanced versatility.

Each individual light head offers independent pan and tilt functionality, complemented by a linear zoom range of 3.5° to 30°. The strobe effect is adjustable with variable speed settings, ensuring dynamic visual displays. For optimal performance, the fixture includes a 16-bit linear dimmer with four selectable dimmer curves, providing smooth and customizable lighting transitions.

Control is facilitated through DMX, with options ranging from 21 to 170 channels, allowing for extensive programming flexibility. The user-friendly LCD display features touch buttons for easy navigation and operation. Power connectivity is streamlined with PowerCon in/out options. Weighing in at 27 kg, this innovative lighting solution is designed for both professional and creative applications.

Technical Specifications

Main Light Source: 5 x 120W RGB-Lime 4-in-1 LEDs with individual pixel control
Outer Circle: 120 x 0.5W RGB 3-in-1 LEDs with section control (3 LEDs per section)
Zoom Angles: 3.5° - 30°
Color Temperature (CTC):7100K ± 100K
Color Rendering Index (CRI):75
Illuminance:3640 lx at 10m (beam); 98 lx at 10m (wash)
Dimmer: 0-100% linear dimming, 16-bit resolution
Strobe Function: 0-20Hz, adjustable speed
Control Modes: DMX512, Auto, Master/Slave, RDM
Channel Options:21CH, 41CH, 71CH, 75CH, 85CH, 170CH
Display: LCD with four touch-button controls
Ingress Protection Rating: IP20
Pan Movement: 59°, 16-bit resolution, individual head movement
Tilt Movement: 221°, 16-bit resolution, individual head movement
Power Connector: PowerCon in/out
Signal Connector: XLR 3-pin in/out + 5-pin in/out
Input Voltage: 100-240V, 50/60Hz
Power Consumption: 620W
