FOS V6

Product code:L005369
Electric Chain Hoist , CE and TUV certified , Lifting Capacity:1000 KG , Lifting Height:25 M , Lifting Speed: 4 M/min , Double Electromagnetic Brake System, Protection Grade: IP 55 , Motor Protector , Overload Protector.
TEXT_PRODUCT_DESCRIPTION
Technical Specifications

TUV & CE Certified
Lifting capacity: 1000 Kg
Lifting height: 25 meters
Lifting speed: 4 meters per minute
Double electromagnetic brake system.
Motor protection against overload
Chassis made from aviation aluminium
Power supply: 220 / 380 Volt AC, 50 Hz.
Weight: 44,4 Kg.
Standard configuration: 25 meters chain and chain bag.


With the Teflon-level painting technology, the aviation aluminium for the chassis construction, the weight is decreased and IP55 protection level is achieved.



Hermetic oily gear box with lifetime warranty & maintenance.




G80 FEC high strength and durable chain, with protection against corrosion. It's shape design allows horizontal flow through the chain hoist, avoiding any change of jamming due to twist.

electromagnetic double brake system and 5-teeth chain wheel, reducing the abrasion and improving the balance performance of the chain.



Rubber design of the hoist sides for bump protection, with slide in handles.
